| W x D x H |
50" x 31" x 82"
|
| Weight |
1500 lb
|
| Power Output | 12 Amps |
| Power Input Type | Electric |
| Primary Power Input | 208-240 V x 60 Hz x 3 PH |
HAMKDL: direct steam stationary mixer kettle horizontal agitator
COOK CHILL, DIRECT STEAM, HORIZONTAL AGITATOR, STATIONARY MIXER KETTLES
CLEVELAND COOK CHILLl STATIONARY HORIZONTAL MIXER KETTLE; leg mounted; 2/3 jacketed, direct steam; 100 psi Steam Jacket Pressure Rating; 316 Stainless Steel Liner; electrically driven Horizontal Agitator; Variable Mixer Speed Control; 3" diameter air operated, flush mounted Piston Draw-Off Valve; spring loaded Scraper Blades; flush mounted Temperature Probe; Automatic Water Meter with Digital Readout; Water Fill Faucet with swing spout; Time/Temperature Chart Recorder (located in Control Center); Spring Assist, one piece Cover (bifold cover with counterweight for 300 gallon model).
|
Capacity
Full 60, 100, 150, 200 or 300 gallon working capacity |
|
Mixer
Variable mixer speed control |
|
Sraper Blades
Spring loaded blades scrape entire heated surface area |
|
Simmer Control
For cooking delicate products |
|
Rim Bar
Heavy duty rim bar |
|
Jacket Rating
100 psi steam jacket rating and safety valve |
|
Agitator
Easily removable agitator without the use of tools |
|
Agitator Interlock
Ceases the agitator rotation when the cover is lifted |
|
Approval
Approved for NSF/ANSI Standard 4 - Commercial Cooking |
|
ASME
Built to current Mechanical Society of American Engineers (ASME) Code Section VIII - Division 1 |
|
Construction
Type 316 stainless steel for all food contact surfaces |
|
Cover
Spring assist, one-piece cover (bifold cover with counterweight for 300 gallon model and higher) |
|
Draw-off Valve
3" diameter air operated, flush mounted piston draw-off valve (requires air compressor) |
|
Faucet
Water fill faucet with swing spout |
|
Mixer Fins
Internal mixing fins for most efficient, uniform mixing, heating and cooling |
|
Mixer Arm
Electrically driven, horizontal agitator mixer arm |
|
Safety Valve
100 psi steam jacket rating and safety valve |
|
Speed Control
Variable mixer speed control |
|
Spiral Flights
For even water cooling |
|
Stop Button
Kettle mounted emergency stop button |
|
Temperature Sensor
Flush mounted, easily removable temperature sensor |
|
USDA
Accepted for use in USDA inspected facilities |
|
Valve Box
Kettle mounted valve box for singl- point utility connections. |
|
NOTE:
This COOK CHILL mixer kettle requires a control panel for operation. (Please specify remote mounted control center or kettle mounted control center.) |
Standard Features for Kettle Control Center
|
HA-MKDL-60-CC
60-gallon horizontal agitator stationary mixer kettle
HA-MKDL-100-CC
100-gallon horizontal agitator stationary mixer kettle
| W x D x H |
57" x 37" x 91"
|
| Weight |
1700 lb
|
| Power Output | 15 Amps |
| Primary Power Input | 208-240 V x 60 Hz x 3 PH |
HA-MKDL-150-CC
150-gallon horizontal agitator stationary mixer kettle
| W x D x H |
62" x 43" x 100"
|
| Weight |
2000 lb
|
| Power Output | 15 Amps |
| Primary Power Input | 208-240 V x 60 Hz x 3 PH |
HA-MKDL-200-CC
200-gallon horizontal agitator stationary mixer kettle
| W x D x H |
653/4" x 48" x 112"
|
| Weight |
2200 lb
|
| Power Output | 22 Amps |
| Primary Power Input | 208-240 V x 60 Hz x 3 PH |
HA-MKDL-300-CC
300-gallon horizontal agitator stationary mixer kettle
| W x D x H |
75" x 52" x 125"
|
| Weight |
3100 lb
|
| Power Output | 22 Amps |
| Primary Power Input | 208-240 V x 60 Hz x 3 PH |
HA-MKDL-350-CC
350-gallon horizontal agitator stationary mixer kettle
| W x D x H |
771/2" x 55" x 135"
|
| Weight |
3600 lb
|
| Power Output | 30 Amps |
| Primary Power Input | 208-240 V x 60 Hz x 3 PH |
DollyFor horizontal agitator |
|
HoistElectric chain hoist for lifting the product loading |
|
Agitator Idler BearingClean-in-place (CIP) agitator idler bearing with hot water/steam connector |
|
Water MeterWater meter for hot and cold kettle fill |
|
Control CenterSingle or dual remote control centerKettle-mounted control center (100 gal. and larger) |
|
CoverStainless steel bifold hinged cover |
|
Elbow3" 90° elbow |
|
ModelsTilting models |
|
BucketLoading bucket and dolly |
|
Pressure RatingsJacket pressure ratings other than standard |
|
ApprovalCRN approval - for Canada |
|
Sizes AvailableAvailable in 400 and 500 gallon sizes |
|
Rim HeightTaller rim height as needed for working platforms |
|
Voltages208/3/60; 240/3/60 and 460/3/60 electric voltages |
|
Voltages, Export380/3/50 or 575/3/60 export voltages |
|
Agitator InterlockCeases the agitator rotation when the cover is lifted |
